Specialist
No contact, no noise, no spark
Automatic protection, reusable
The performance meets the UL1434 standard
Application
Electronic ballasts, energy-saving lamps, adapters
Charger, energy meter, multimeter
Communication equipment, micro motor
| P/N | Rated Zero Power Resistance | Max. Non Operating Current at 25℃ | Max. Non Operating Current at 40℃ | Trip Current at 25℃ It(mA) | Tripping time atmax current T(Set) | Max. Current Imax(A) | Max. Voltage Vmax(V) | Specifications |
| WMZ12A-85LB10RM150 | 10Ω±20% | 150 | 120 | 300 | 0.55 | 3.0 | 250 | Download |
| WMZ12A-85B12RM060 | 12Ω±20% | 90 | 60 | 160 | 0.2 | 2.0 | 250 | Download |
| WMZ12A-105B18RM110 | 18Ω±20% | 135 | 110 | 270 | 0.18 | 3.0 | 250 | Download |
| WMZ12A-70LB20RM070 | 20Ω±20% | 110 | 70 | 200 | 0.3 | 3.0 | 250 | Download |
| WMZ12A-110B35RM070 | 35Ω±20% | 90 | 70 | 230 | 0.45 | 3.0 | 250 | Download |
| WMZ12A-108B35RM070 | 35Ω±20% | 90 | 70 | 230 | 0.45 | 4.6 | 245 | Download |
| WMZ12A-85LB50RM060 | 50Ω±20% | 75 | 60 | 150 | 0.2 | 3.0 | 250 | Download |
| WMZ12A-85LB50RM060 | 50Ω±20% | 75 | 60 | 150 | 0.2 | 3.0 | 380 | Download |
| WMZ12A-85LB55RM060 | 55Ω±20% | 70 | 60 | 150 | 0.2 | 3.0 | 250 | Download |
| WMZ12A-85LB55RM060 | 55Ω±20% | 70 | 60 | 150 | 0.2 | 3.0 | 650 | Download |
| WMZ12A-110B35RM070 | 35Ω±20% | 100 | 70 | 230 | 0.2 | 3.0 | 245 | Download |
| WMZ12A-110B50RM090 | 50Ω±20% | 90 | 60 | 180 | 0.15 | 4.5 | 250 | Download |
| WMZ12A-110H35RM060 | 35Ω±20% | 90 | 60 | 180 | 0.2 | 2.5 | 230 | Download |
| WMZ12A-110LB50RM060 | 50Ω±20% | 90 | 60 | 190 | 0.2 | 2.5 | 250 | Download |
| WMZ12A-115B25RM085 | 25Ω±20% | 130 | 85 | 260 | 0.3 | 3.0 | 250 | Download |
| WMZ12A-110B35RM070 | 35Ω±20% | 110 | 70 | 230 | 0.2 | 3.0 | 250 | Download |
| WMZ12A-85C10RM100 | 10Ω±20% | 130 | 100 | 300 | 0.2 | 3.0 | 250 | Download |
