Specialist
◆ Fully compatible with current industry standards
◆ Very low internal resistance
◆ UL(E352136), C-UL(E352136), TUV(R50322001)
◆ RoHS, Reach, HF compliance
Application
◆ Any application that requires protection at low resistances
◆ Cellular phones
◆ Laptop computers
◆ Rechargeable battery pack protection.
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TLC-LSML1000/16 | 10.0 | 20.0 | 16 | 40 | 40.0 | 7.0 | 1.0 | 0.0003 | 0.005 | Download |
| TLC-LSML1000/12 | 10.0 | 20.0 | 12 | 50 | 40.0 | 7.0 | 1.50 | 0.0003 | 0.005 | Download |
| TLC-LSML750/12 | 7.5 | 15.0 | 12 | 50 | 37.5 | 7.0 | 1.50 | 0.001 | 0.013 | Download |
| TLC-LSML600/12 | 6.0 | 12.0 | 12 | 50 | 30.0 | 7.0 | 1.50 | 0.001 | 0.013 | Download |
| TLC-LSML500/16 | 5.0 | 10.0 | 16 | 50 | 25.0 | 7.0 | 1.50 | 0.001 | 0.012 | Download |
