Specialist
◆ Fully compatible with current industry standards
◆ Very low internal resistance
◆ UL(E352136), C-UL(E352136), TUV(R50322001)
◆ RoHS, Reach, HF compliance
Application
◆ Any application that requires protection at low resistances
◆ Cellular phones
◆ Laptop computers
◆ Rechargeable battery pack protection.
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TLC-MSML900T | 9.0 | 18.0 | 12.0 | 50 | 45.0 | 5.00 | 1.50 | 0.0005 | 0.007 | Download |
| TLC-MSML800 | 8.0 | 16.0 | 6.0 | 50 | 40.0 | 5.00 | 1.50 | 0.0005 | 0.008 | Download |
| TLC-MSML750/12D | 7.5 | 15.0 | 12.0 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | Download |
| TLC-MSML750/12 | 7.5 | 15.0 | 12.0 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | Download |
| TLC-MSML750 | 7.5 | 15.0 | 6/8 | 50 | 37.5 | 5.00 | 1.50 | 0.0005 | 0.008 | Download |
| TLC-MSML700T | 7.0 | 14.0 | 24.0 | 50 | 35.0 | 5.00 | 1.50 | 0.0007 | 0.010 | Download |
| TLC-MSML700 | 7.0 | 14.0 | 6.0 | 50 | 35.0 | 5.00 | 1.50 | 0.0007 | 0.010 | Download |
| TLC-MSML500T | 5.0 | 10.0 | 24.0 | 50 | 30.00 | 5.00 | 1.50 | 0.001 | 0.013 | Download |
| TLC-MSML500/16 | 5.0 | 10.0 | 16.0 | 50 | 30.00 | 5.00 | 1.50 | 0.001 | 0.013 | Download |
| TLC-MSML500/12 | 5.0 | 10.0 | 12.0 | 50 | 30.00 | 5.00 | 1.50 | 0.001 | 0.013 | Download |
| TLC-MSML500 | 5.0 | 10.0 | 6.0 | 50 | 30.00 | 5.00 | 1.50 | 0.002 | 0.012 | Download |
| TLC-MSML450T | 4.50 | 9.00 | 24.0 | 50 | 22.5 | 5.00 | 1.50 | 0.002 | 0.013 | Download |
| TLC-MSML450/12 | 4.50 | 9.00 | 12.0 | 50 | 22.5 | 5.00 | 1.50 | 0.002 | 0.013 | Download |
| TLC-MSML450 | 4.50 | 9.00 | 6.0 | 50 | 22.5 | 5.00 | 1.50 | 0.002 | 0.013 | Download |
| TLC-MSML400/16 | 4.00 | 8.00 | 16.0 | 50 | 20.00 | 5.00 | 1.50 | 0.002 | 0.014 | Download |
| TLC-MSML400/12 | 4.00 | 8.00 | 12.0 | 50 | 20.00 | 5.00 | 1.50 | 0.004 | 0.014 | Download |
| TLC-MSML400 | 4.00 | 8.00 | 6.0 | 50 | 20.00 | 5.00 | 1.50 | 0.002 | 0.013 | Download |
| TLC-MSML350/12 | 3.50 | 7.00 | 12.0 | 50 | 17.50 | 5.00 | 1.50 | 0.003 | 0.020 | Download |
| TLC-MSML350 | 3.50 | 7.00 | 6.0 | 50 | 17.50 | 5.00 | 1.50 | 0.003 | 0.020 | Download |
| TLC-MSML300/12 | 3.00 | 6.00 | 12.0 | 50 | 15.00 | 5.00 | 1.50 | 0.004 | 0.025 | Download |
| TLC-MSML300 | 3.00 | 6.00 | 6.0 | 50 | 15.00 | 5.00 | 1.50 | 0.004 | 0.025 | Download |
| TLC-MSML250 | 2.50 | 6.00 | 6.0 | 50 | 8.00 | 5.00 | 1.50 | 0.003 | 0.020 | Download |
| TLC-MSML200/12 | 2.00 | 5.00 | 12.0 | 50 | 8.00 | 5.00 | 1.50 | 0.004 | 0.024 | Download |
| TLC-MSML200 | 2.00 | 5.00 | 6.0 | 50 | 8.00 | 5.00 | 1.50 | 0.004 | 0.024 | Download |
