Specialist
-
Fully compatible with current industry standards
Very low internal resistance
UL(Pending), C-UL(Pending), TUV(Pending)
RoHS，Reach，HF compliance
Application
Any application that requires protection at low resistances
Cellular phones
-
Rechargeable battery pack protection.
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TLC-ASML100 | 1.00 | 2.00 | 6.0 | 50 | 8.00 | 5.00 | 0.50 | 0.025 | 0.250 | Download |
| TLC-ASML050 | 0.50 | 1.00 | 6.0 | 50 | 8.00 | 1.00 | 0.50 | 0.040 | 0.400 | Download |
| TLC-ASML035 | 0.35 | 0.70 | 6.0 | 50 | 8.00 | 1.00 | 0.50 | 0.050 | 0.700 | Download |
| TLC-ASML020 | 0.20 | 0.50 | 6.0 | 50 | 1.00 | 1.00 | 0.50 | 0.100 | 1.250 | Download |
| TLC-ASML010 | 0.10 | 0.30 | 6.0 | 50 | 0.50 | 1.00 | 0.50 | 0.150 | 2.000 | Download |
