Specialist
◆ Fully compatible with current industry standards
◆ Very low internal resistance
◆ UL(E352136), C-UL(E352136), TUV(R50306075)
◆ RoHS, Reach, HF compliance
Application
◆ Any application that requires protection at low resistances
◆ Cellular phones
◆ Laptop computers
◆ Rechargeable battery pack protection.
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TLC-NSML750 | 7.50 | 15.00 | 6.0 | 50 | 38.75 | 2.00 | 1.50 | 0.001 | 0.017 | Download |
| TLC-NSML700 | 7.00 | 14.00 | 6.0 | 50 | 35.00 | 2.00 | 1.50 | 0.001 | 0.017 | Download |
| TLC-NSML650 | 6.50 | 13.00 | 6.0 | 50 | 32.50 | 2.00 | 1.50 | 0.001 | 0.018 | Download |
| TLC-NSML600 | 6.00 | 12.00 | 6.0 | 50 | 30.00 | 2.00 | 1.50 | 0.001 | 0.018 | Download |
| TLC-NSML550 | 5.50 | 11.0 | 6.0 | 50 | 27.50 | 2.00 | 1.50 | 0.002 | 0.018 | Download |
| TLC-NSML500/12 | 5.00 | 10.00 | 12.0 | 50 | 25.00 | 5.00 | 1.50 | 0.002 | 0.013 | Download |
| TLC-NSML500 | 5.00 | 10.00 | 6.0 | 50 | 25.00 | 2.00 | 1.50 | 0.002 | 0.018 | Download |
| TLC-NSML450/12 | 4.50 | 9.00 | 12.0 | 50 | 22.50 | 5.00 | 1.50 | 0.002 | 0.014 | Download |
| TLC-NSML450 | 4.50 | 9.00 | 6.0 | 50 | 22.50 | 2.00 | 1.50 | 0.002 | 0.018 | Download |
| TLC-NSML400/12 | 4.00 | 8.00 | 12.0 | 50 | 8.00 | 5.00 | 1.20 | 0.003 | 0.014 | Download |
| TLC-NSML400 | 4.00 | 8.00 | 6.0 | 50 | 20.00 | 2.00 | 1.20 | 0.003 | 0.020 | Download |
| TLC-NSML380 | 3.80 | 8.00 | 6.0 | 50 | 20.00 | 2.00 | 1.20 | 0.003 | 0.022 | Download |
| TLC-NSML350/12 | 3.50 | 7.00 | 12.0 | 50 | 8.00 | 5.00 | 1.50 | 0.003 | 0.018 | Download |
| TLC-NSML350 | 3.50 | 9.00 | 6.0 | 50 | 18.50 | 2.00 | 1.20 | 0.003 | 0.030 | Download |
| TLC-NSML300/12 | 3.00 | 6.00 | 12.0 | 50 | 8.00 | 5.00 | 1.20 | 0.003 | 0.020 | Download |
| TLC-NSML300 | 3.00 | 6.00 | 6.0 | 50 | 8.00 | 5.00 | 1.20 | 0.003 | 0.020 | Download |
| TLC-NSML260 | 2.60 | 5.00 | 6.0 | 50 | 8.00 | 4.00 | 1.20 | 0.003 | 0.035 | Download |
| TLC-NSML200/12 | 2.00 | 4.00 | 12.0 | 50 | 8.00 | 5.00 | 1.20 | 0.008 | 0.040 | Download |
| TLC-NSML200 | 2.00 | 4.00 | 6.0 | 50 | 8.00 | 1.00 | 1.20 | 0.005 | 0.055 | Download |
| TLC-NSML190 | 1.90 | 4.90 | 6.0 | 50 | 8.00 | 5.00 | 1.20 | 0.010 | 0.060 | Download |
| TLC-NSML175 | 1.75 | 3.50 | 6.0 | 50 | 8.00 | 1.00 | 1.20 | 0.005 | 0.055 | Download |
| TLC-NSML150 | 1.50 | 3.00 | 6.0 | 50 | 8.00 | 0.30 | 1.20 | 0.010 | 0.065 | Download |
| TLC-NSML110 | 1.10 | 2.20 | 6.0 | 50 | 8.00 | 0.30 | 1.20 | 0.015 | 0.100 | Download |
