Specialist
Fully compatible with current industry standards
Very low internal resistance
UL(Pending), C-UL(Pending), TUV(Pending)
RoHS，Reach，HF compliance
Application
Any application that requires protection at low resistances
Cellular phones
Rechargeable battery pack protection.
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TLC-FSML300 | 3.00 | 6.00 | 6.0 | 50 | 8.00 | 5.00 | 1.10 | 0.006 | 0.055 | Download |
| TLC-FSML260 | 2.60 | 5.20 | 6.0 | 50 | 8.00 | 5.00 | 1.10 | 0.007 | 0.060 | Download |
| TLC-FSML250 | 2.50 | 5.00 | 6.0 | 50 | 8.00 | 5.00 | 0.60 | 0.004 | 0.050 | Download |
| TLC-FSML200 | 2.00 | 4.00 | 6.0 | 50 | 8.00 | 5.00 | 0.70 | 0.008 | 0.065 | Download |
| TLC-FSML175 | 1.75 | 3.50 | 6.0 | 50 | 8.00 | 5.00 | 0.50 | 0.009 | 0.070 | Download |
| TLC-FSML150 | 1.50 | 3.00 | 6.0 | 50 | 8.00 | 2.00 | 0.50 | 0.015 | 0.085 | Download |
| TLC-FSML125 | 1.25 | 2.50 | 6.0 | 50 | 8.00 | 0.40 | 0.50 | 0.015 | 0.095 | Download |
| TLC-FSML110 | 1.10 | 2.20 | 6.0 | 50 | 8.00 | 0.30 | 0.50 | 0.030 | 0.120 | Download |
| TLC-FSML100 | 1.00 | 2.00 | 6.0 | 50 | 8.00 | 2.00 | 0.50 | 0.020 | 0.100 | Download |
| TLC-FSML075 | 0.75 | 1.50 | 6.0 | 50 | 8.00 | 2.00 | 0.50 | 0.038 | 0.250 | Download |
| TLC-FSML050 | 0.50 | 1.00 | 6.0 | 50 | 8.00 | 0.10 | 0.50 | 0.060 | 0.350 | Download |
| TLC-FSML035 | 0.35 | 0.70 | 6.0 | 50 | 8.00 | 0.10 | 0.70 | 0.065 | 0.420 | Download |
