Specialist
◆ Lower power consumption by ultra-low resistance
◆ Alternative shapes and sizes available on request
◆ UL(E352136), C-UL(E352136), TUV(Pending)
◆ RoHS, Reach, HF compliance
Application
◆ Battery protection
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TAL1000 | 10.0 | 24.0 | 10 | 50 | 50.00 | 5.00 | 1.5 | 0.001 | 0.004 | Download |
| TAL600-L2 | 6.00 | 14.4 | 10 | 50 | 30.00 | 5.00 | 1.5 | 0.001 | 0.009 | Download |
| TAL600 | 6.00 | 12.0 | 6 | 50 | 30.00 | 5.00 | 1.5 | 0.002 | 0.010 | Download |
| TAL500-L2 | 5.00 | 12.0 | 10 | 50 | 25.00 | 5.00 | 1.5 | 0.001 | 0.010 | Download |
| TAL500 | 5.00 | 9.50 | 6 | 40 | 25.00 | 3.00 | 1.3 | 0.002 | 0.008 | Download |
| TAL450 | 4.50 | 9.50 | 6 | 40 | 22.50 | 5.00 | 1.3 | 0.002 | 0.008 | Download |
| TAL410 | 4.10 | 9.20 | 6 | 40 | 20.50 | 5.00 | 1.3 | 0.002 | 0.008 | Download |
| TAL370 | 3.70 | 9.00 | 6 | 40 | 18.50 | 5.00 | 1.3 | 0.002 | 0.010 | Download |
| TAL350 | 3.50 | 8.10 | 6 | 40 | 17.50 | 5.00 | 1.3 | 0.003 | 0.009 | Download |
| TAL310 | 3.10 | 8.00 | 6 | 40 | 15.50 | 3.00 | 1.3 | 0.003 | 0.011 | Download |
| TAL300 | 3.00 | 8.00 | 6 | 40 | 15.00 | 3.00 | 1.3 | 0.003 | 0.010 | Download |
| TAL280 | 2.80 | 5.60 | 6 | 40 | 14.00 | 3.00 | 1.0 | 0.004 | 0.010 | Download |
| TAL270-L2 | 2.70 | 6.20 | 6 | 40 | 13.50 | 3.00 | 1.0 | 0.004 | 0.015 | Download |
| TAL270 | 2.70 | 6.20 | 6 | 40 | 13.50 | 3.00 | 1.0 | 0.004 | 0.010 | Download |
| TAL260 | 2.60 | 6.00 | 6 | 40 | 13.00 | 3.00 | 1.0 | 0.004 | 0.010 | Download |
| TAL250 | 2.50 | 8.00 | 6 | 40 | 12.50 | 3.00 | 1.0 | 0.004 | 0.012 | Download |
| TAL210 | 2.10 | 5.60 | 6 | 40 | 10.50 | 3.00 | 1.0 | 0.005 | 0.012 | Download |
| TAL200 | 2.00 | 5.30 | 6 | 40 | 10.00 | 3.00 | 1.0 | 0.006 | 0.012 | Download |
| TAL190 | 1.90 | 4.90 | 6 | 40 | 9.50 | 3.00 | 1.0 | 0.006 | 0.013 | Download |
| TAL180 | 1.80 | 4.60 | 6 | 40 | 9.00 | 3.00 | 1.0 | 0.006 | 0.013 | Download |
| TAL175 | 1.75 | 4.50 | 6 | 40 | 8.70 | 3.00 | 1.0 | 0.006 | 0.015 | Download |
| TAL170 | 1.70 | 4.20 | 6 | 40 | 8.50 | 3.00 | 1.0 | 0.008 | 0.017 | Download |
| TAL160 | 1.60 | 4.00 | 6 | 40 | 8.00 | 3.00 | 1.0 | 0.009 | 0.018 | Download |
| TAL140 | 1.40 | 3.60 | 6 | 40 | 7.00 | 3.00 | 1.0 | 0.010 | 0.020 | Download |
| TAL120 | 1.20 | 3.00 | 6 | 40 | 6.00 | 3.00 | 1.0 | 0.011 | 0.025 | Download |
| TAL110 | 1.10 | 2.80 | 6 | 40 | 5.50 | 3.00 | 1.0 | 0.011 | 0.025 | Download |
