Specialist
◆ Resettable overcurrent protection
◆ Very low resistance
◆ UL(E352136), C-UL(E352136), TUV(Pending)
◆ RoHS,Reach,HF compliance
Application
◆ Li-ion cell
| P/N | IH(A) | IT(A) | Vmax(V) | I max(A) | T (Max time to trip) (A) |
T (Max time to trip) (Sec) |
Pd typ（W） | R min(Ω) | R max(Ω) | Specifications |
| TD350-3 | 3.50 | 7.00 | 15 | 40 | 10 | <10 | 2.50 | 0.008 | 0.016 | Download |
| TD350-2 | 3.50 | 7.00 | 15 | 40 | 10 | <10 | 2.50 | 0.0075 | 0.016 | Download |
| TD350-1 | 3.50 | 7.00 | 15 | 40 | 10 | <10 | 2.50 | 0.008 | 0.016 | Download |
| TD250-2 | 2.50 | 5.00 | 15 | 40 | 10 | 5 | 2.50 | 0.012 | 0.017 | Download |
| TD250-1 | 2.50 | 5.00 | 15 | 40 | 10 | 10 | 2.50 | 0.006 | 0.016 | Download |
